Products

ETON smt chip mounter for electric car making


Single Module SMT Precision Mounter Machine
Model:HT10S
◇Applied to 0201-40*40mm tape reel package and IC tray material
◇10 Heads with 48000CPH optimal speed
◇XYZ axis all adopt high-end magnetic linear-motor
◇Each head us independently controlled by separately driver, each nozzle can independently test CPK
Image Name

YT40S PICK AND PLACE MACHINE


Breaking through the industry convention, the four-module ultra-high-speed pick and place machine, can mount two products and four PCB board at the same time.
Model: YT40S
◇ Four Gantry with Four lane, Four mounting module mounting independently at the same time;
◇ Flexible PCB handling capabilities;
◇ X, Y, Z axis all adopt self- developed high-end magnetic linear motor;
◇ Support automatic nozzle change function(option);
◇ Low energy consumption, 220V single-phase;
◇ Each nozzle could be CPK testing independently;
◇ Apply to 0201~15*15mm tape reel package
Image Name

High Precision Double Head 98000 CPH Linear Motor SMT Mounter Machine YT20S


Dual Module SMT Precision Mounter Machine

Model: YT20S
◇ Applied to 0201-40*40 smd components
◇ Support high precision fixed vision camera option
◇ 20 Heads with 98000 CPH mounting speed
◇ Flexible Production with more option function
Image Name

Flexible Efficiency Intelligent SMT Mounter Machine YT10S


Single Module SMT Precision Mounter Machine

Model: YT10S
◇ Applied to 0201-40*40 SMD components
◇ Support high precision fixed vision camera option
◇ 10 Heads with 48000 CPH mounting speed
◇ Flexible Production with more option function
Image Name

ETON VALUE SERIES High Efficiency 500000CPH T9-2S Mounter for Roll to Roll


Productivity And Flexibility SMT Mounter

Model: T9-2S
◇ 500000CPH Ultra-high speed machine
◇ 136 nozzles and 136 feeders
◇ Apply for 50m/100m and any length of strip light
◇ Diverse Functions; Efficient Production
Image Name

High Capacity SMT Mounter 250000CPH HT-T9 for Roll to Roll


Full Automatic LED Strip making pick and place machine

Model: HT-T9
◇ 250000CPH Ultra-high speed machine
◇ 68 nozzles and 68 feeders
◇ Apply for 50m/100m and any length of strip light
◇ Diverse Functions; Efficient Production
Image Name

Dual arm magnetic linear LED high speed pick and place machine HT-F9 with 250000 CPH


Productivity And Flexibility SMT Mounter

Model: HT-F9
◇ 250000CPH Ultra-high speed machine
◇ 68 nozzles and 68 feeders
◇ Apply to Max 1.2 M rigid pcb and flexible strip
◇ Automatic feeding function
Image Name

LED Tube making high speed pick and place machine HT-F7S 180000CPH


Productivity And Flexibility SMT Mounter

Model: HT-F7S
◇ 180000CPH Ultra-high speed machine
◇ 34 nozzles and 68 feeders
◇ Apply to Max 1.2 M rigid pcb and flexible strip
◇ Automatic feeding function
Image Name

Eton Glory Series - YT40L High-end Roll-to-Roll High-Speed Chip Mounter


Quad-arm, dual-track, high-speed roll-to-roll chip mounter
Image Name
