ETON smt chip mounter for electric car making

Single Module SMT Precision Mounter Machine
Model:HT10S
◇Applied to 0201-40*40mm tape reel package and IC tray material
◇10 Heads with 48000CPH optimal speed
◇XYZ axis all adopt high-end magnetic linear-motor
◇Each head us independently controlled by separately driver, each nozzle can independently test CPK

Key words:

Product Inquiry:

Product Description

Features

  • Applied to 0201-40*40 SMD components
  • Support high precision fixed vision camera
  • 10 Heads with 48000 CPH mounting speed
  • Flexible Production with more option function

Parameter

Model

HT10S

PCB size(L*W)

Max size: 500mm*450mm

Mini Size: 50*50mm

PCB thickness

0.5-5mm

Calibration method

Vision alignment+Mark correction

Repeat precision

CHIP±0.03mm QFP±0.025mm CPK1.03σ)

Mounting speed

48000 CPH(Optimum speed)

Components range

0201-15*15mm packing material and IC material

(optional fixed identification camera for 0201-40*40mm)

Power

1Φ220AC 50HZ 1.5KW

Operating environment

23℃±3

Transmission direction

Standard: Single direction

Position mode

Optical

X,Y,X Axis driveway

High-end magnetic linear motor

No.of Feeder station

52 PCS

No.of Heads

10 PCS

MES System interface

Customized

Application
