ETON VALUE SERIES High Efficiency 500000CPH T9-2S Mounter for Roll to Roll
Belongs to category:
Key words:
ETON
Product Description
Features
1.HIGH PRODUCTIVITY
ETON Tech Adjustable Placement Head
Component picking position can be adjusted according to PCB pad pitch, min 6.5mm. Apply to LED 3014/3020/2835/5050 resistor, capacitor,bridge rectifier etc. wide component range.
Unique Design Component Leaking Detection And Individual Component Refill Function
Recognition camera record the component leaking position of PCB,and fill the missing component accordingly.
Ultra-high-speed-Capacity
The placement head adopts the method of two times picking and once placing.The placement time greatly minimized\with the improved placement way, excellent optimum capacity reach 500000 CPH.
2. FLEXIBLE PRODUCTION
Adjust the conveying platform according to various roll to roll strips,range 250±10mm,the max length range is 1M per cycle.
The distance of the feeder station can be flexibly adjusted to achieve group picking and group placing,so as to realize the function of two time picking and once placing.The range of feeding station is double of placement head, and can produce four kinds of materials at the same time.
Intelligent electric feeder,supporting high-speed machine series.
3. HIGH PERFORMANCE
- Flight recognition camera,no pause to detect the presence or absence of components,component adsorption state,prevent placement errors.
- Automatic production with identification data,correction and fill missing components automatically.
- The clamping rod is driven by the air cylinder to correct the materials taken by mounting head.
- With the function of filling missing component automatically, realize Industry 4.0 Unmanned Workshop.
- Compliant with CE standards.
Parameter
|
Model |
T9-2S |
|
PCB |
|
|
PCB Length Width |
250 (±10mm)*Any Length |
|
PCB Thickness |
0.1-0.5mm |
|
PCB Clamping |
Vacuum adsorption, cylinder clamping, track width adjustable |
|
Mounting way |
Group picking and group placing |
|
Vision System |
|
|
Mounting Height |
≤5mm |
|
Mounting Speed |
Double side:500000CPH,single side:250000CPH(Optimum speed) |
|
Components |
LED3014/3020/2835/5050 and resistor,capacitors,bridge rectifiers etc. |
|
Feeding System |
|
|
No. of Feeder station |
Double side:136PCS(single side:68PCS) |
|
No.of head |
Double side:136PCS(single side:68PCS) |
