HT-E5S single module magnetic levitation multifunctional placement machine
HT-E5S single module magnetic levitation multifunctional placement machine
HT-E5S single module magnetic levitation multifunctional placement machine
HT-E5S single module magnetic levitation multifunctional placement machine

Newly launched the HT-E5S magnetic levitation multi-function placement machine with faster placement speed and higher precision

Product introduction
Operation manual



HT-E5Single module Multifunctional placement machine Technical parameters:

Dimensions

Long

1650mm

wide

1200mm

High

1570mm

Total weight

1200Kg

Circuit board

PCB board size

Maximum: 500*350mm Minimum: 100*100mm

PCB board thickness

Thickness: 0.5 to 3mm

PCB board fixing method

Electric+Pneumatic



Patch method

Group taking and sub-posting, sub-taking and sub-posting

Operating system

System

Windows 7

Software

Independent research and development

Display

Touch screen display

Input device

Keyboard, mouse

Visual system

Identify the number of cameras

Two sets of imported cameras



Flight recognition visual alignment, MARK correction



Repeat accuracy

±0.02mm



Component height

<18mm (automatic conversion)



Placement speed

40000 CPH



Mounting parts range

With lamp beads, capacitors, resistors, IC special-shaped components, etc. (Max: 17mm, Min: 0402)



Component span

0.2mm



Using power

380AC 50Hz



Power supply power

4KW



Using environment

23℃±3℃



rail drive

Maximum length: 500mm



Transmission speed

>500mm/sec



Transmission direction

Bidirectional



Transmission method

Auto online



Air pressure

>5.0Kg/ CM²



Electrical control

ETON independent research and development



XYZ axis drive mode

High-end magnetic levitation motor + servo motor

Feeding system

The number of feeders that can be placed

 Single module   30 PCS

Number of nozzles

Single module   8 PCS

Feeder type

Dual motor electronic feeder

(Note: Actual production capacity and accuracy vary with customer products)
